Binder | Model BF 260 | Standard-Incubators with forced convection
Binder | Model BD 260 | Standard-Incubators with natural convection
Temperature range: +7 °C above ambient temperature to +100 °C
High temperature accuracy thanks to APT.line™ technology
Forced convection
Controller with LCD display
Electromechanical control of the exhaust air flap
Inner door made of tempered safety glass
2 chrome-plated racks
Class 3.1 integrated independent temperature safety device (DIN 12880) with visual
Ergonomic handle design
USB port for recording data
Description | BF260-230V * | BF260UL-120V * |
Article Number | 9010-0319 | 9010-0320 |
Performance Data Temperature | ||
Temperature range +7 °C above ambient temperature to [°C] | 100 | 100 |
Temperature range +8 °C above ambient temperature to [°C] | ||
Temperature range +10 °C above ambient temperature to [°C] | ||
Temperature variation at 37 °C [± K] | 0.2 | 0.3 |
Temperature fluctuation at 37 °C [± K] | 0.1 | 0.1 |
Heating-up time to 37 °C [min] | 7 | 7 |
Recovery time after 30 seconds door open at 37 °C [min] | 3 | 3 |
Electrical data | ||
Rated Voltage [V] | 230 | 120 |
Power frequency [Hz] | 50/60 | 60 |
Nominal power [kW] | 0.9 | 1 |
Unit fuse [A] | 8 | 12.5 |
Phase (Nominal voltage) | 1~ | 1~ |
Measures | ||
Interior volume [L] | 257 | 257 |
Net weight of the unit (empty) [kg] | 82 | 82 |
Permitted load [kg] | 270 | 270 |
Load per rack [kg] | 40 | 40 |
Wall clearance back [mm] | 160 | 160 |
Wall clearance sidewise [mm] | 100 | 100 |
Internal Dimensions | ||
Width [mm] | 650 | 650 |
Height [mm] | 780 | 780 |
Depth [mm] | 510 | 510 |
Doors | ||
Inner doors | ||
Unit doors | 1 | 1 |
Housing dimensions not incl. fittings and connections | ||
Width net [mm] | 810 | 810 |
Height net [mm] | 845 | 845 |
Depth net [mm] | 760 | 760 |
Environment-specific data | ||
Energy consumption at 37 °C [Wh/h] | 65 | 65 |
Sound-pressure level [dB(A)] | 43 | 43 |
Fixtures | ||
Number of shelves (std./max.) | 2/8 | 2/8 |
