Binder Model UF V 700 | Ultra Low Temperature Freezer with Climate-neutral Refrigerants

Binder

Model UF V 700 | Ultra Low-Temperature Freezer with Climate-neutral Refrigerants

Binder Test Cihazları Türkiye Distribütörü | Enfor

* Temperature range: -90 °C to -40 °C
* Lowest energy consumption in its class
* Powerful cascade compressor cooling unit
* Environmentally friendly refrigerants R-290 and R-170
* Thermal insulation with unique long-life VIPs (vacuum insulation panels)
* Innovative door gasket concept reduces buildup of ice
* Ergonomic door handle
* Rust-proof interior made completely of stainless steel
* Detachable inner doors made of stainless steel
* 3 stainless-steel shelves providing flexible placement
* Water cooling (depending on version)
* Zero-voltage alarm contact for in-house alarm system
* Internal data logger, measured values can be read out in open format via USB
* Ethernet interface
* 2 access ports, Ø 28 mm, rear

Description	UFV700-230V *	UFV700-230V-W *	UFV700UL-240V *	UFV700UL-120V *

Article Number	9020-0348	9020-0350	9020-0354	9020-0352
Performance Data Temperature
Temperature range	-90…-40	-90…-40	-90…-40	-90…-40
Temperature variation at -80 °C [± K]	2.5	2.5	2.5	2.5
Temperature fluctuation at -80 °C [± K]	1.5	1.5	1.5	1.5
Cooling down time from 22 °C to -80 °C [min]	450	450	450	450
Warm-up time during power failure from -80 °C / -122 °F to -60 °C / -76 °F [min]	250	250	250	250
Electrical data
Rated Voltage [V]	230	230	240	120
Power frequency [Hz]	50	50	60	60
Nominal power [kW]	1.6	1.6	1.6	1.4
Unit fuse [A]	10	10	10	13
Phase (Nominal voltage)	1~	1~	1~	1~
Measures
Interior volume [L]	700	700	700	700
Net weight of the unit (empty) [kg]	289	289	289	289
Permitted load [kg]	200	200	200	200
Permitted load of individual compartment [kg]	50	50	50	50
Wall clearance back [mm]	100	100	100	100
Wall clearance sidewise [mm]	250	250	250	250
Internal Dimensions
Width [mm]	890	890	890	890
Height [mm]	1300	1300	1300	1300
Depth [mm]	605	605	605	605
Doors
Unit doors	1	1	1	1
Housing dimensions not incl. fittings and connections
Width net [mm]	1110	1110	1110	1110
Height net [mm]	1966	1966	1966	1966
Depth net [mm]	938	938	938	938
Environment-specific data
Energy consumption at set-point -80 °C and ambient temperature = 21 °C [kWh/d]	8.1	8.1	8.1	8.1
Average heat dissipation at set-point -80 °C and ambient temperature = 21 °C [W]	340	340	340	340
Sound-pressure level [dB(A)]	47	47	47	47
Fixtures
Number of shelves (std./max.)	3/13	3/13	3/13	3/13
Load-variants
Freezer racks per compartment	6	6	6	6
Cryoboxes, 50 mm	528	528	528	528
