Lovibond TG 268 Series Color Measurement Instrument 403045

Colour Type

Opaque

Display

TFT 3.5 inch, capacitive touch screen

Interfaces

USB
RS 232

Measurement Range

0 - 10 gloss units, reproducibility ± 0.1 gloss units, reproducibility ± 0.2 gloss units
10 - 100 gloss units, reproducibility ± 0.2 gloss units, reproducibility ± 0.5 gloss units
100 - 2000 gloss units, reproducibility ± 0.2% gloss units, reproducibility ± 0.5% gloss units

Internal Storage

Basic Mode: 1000 ; Statistical Mode: 5000 ; Continuous Mode: 5000

Measuring Angle

20° / 60° / 85°

Measuring Area

20°: 10 x10 ; 60°: 9 x15 ; 85°: 5 x 36

Measuring Range

20°: 0 - 2000 GU ; 60°: 0 - 1000 GU ; 85°: 0 - 160 GU

Power Supply

3200 mAh Li-ion Battery

Division Value

0.1 GU

Battery Life Time

> 1000 times (within 8 hours)

Measurement Time

1.0 s

Repeatability

± 1.2 %

Portability

Portable

Environmental Conditions

Operating Temperature 0-40 °C (32 104 °F) ; Humidity < 85 % relative humidity, non condensing

Stock Conditions

Storage Temperature -20-50 °C (-4-122 °F)

Languages User Interface

English

Dimensions

160 x 90 x 75 mm

Weight

350 g
