* Temperature range: +5 °C above ambient temperature to +300 °C
* APT.line™ preheating chamber technology
* Adjustable fan speed
* Adjustable exhaust air flap
* Controller with time-segment and real-time programming
* 2 chrome-plated racks
* Class 2 independent adjustable temperature safety device (DIN 12880) with visual alarm
* Computer interface: RS 422

Description	FP720-400V *	FP720UL-208V *

Article Number	9010-0267	9010-0268
Performance Data Temperature
Temperature range +5 °C above ambient temperature to [°C]	300	300
Temperature variation at 150 °C [± K]	2	2
Temperature fluctuation at 150 °C [± K]	0.3	0.3
Heating-up time to 150 °C [min]	39	39
Recovery time after 30 seconds door open at 150 °C [min]	20	20
Air change data
Air change (approx.) at 150 °C [x/h]	12	12
Electrical data
Rated Voltage [V]	400	208
Power frequency [Hz]	50/60	60
Nominal power [kW]	5	5
Unit fuse [A]	3 x 16	3 x 16
Phase (Nominal voltage)	3~	3~
Measures
Interior volume [L]	720	720
Net weight of the unit (empty) [kg]	194	194
Permitted load [kg]	120	120
Load per rack [kg]	45	45
Wall clearance back [mm]	160	160
Wall clearance sidewise [mm]	100	100
Internal Dimensions
Width [mm]	1000	1000
Height [mm]	1200	1200
Depth [mm]	610	610
Housing dimensions not incl. fittings and connections
Width net [mm]	1235	1235
Height net [mm]	1530	1530
Depth net [mm]	865	865
Environment-specific data
Energy consumption at 150 °C [Wh/h]	1320	1320
Fixtures
Number of shelves (std./max.)	2/16	2/16
